MODEL:
PT-2535FP
Dimension:
Electrical   Characteristics:
Model No. PT-2535FP
Rated Voltage (VDC) 12
Operating Voltage (VDC) 3¡ã24
*Rated Current (mA) 20max
*Sound Output at 10 cm (dB) ≥85
*Resonant Frequency (Hz) 3500¡Ó500
Operating Temperature (¢J) -20 ¡ã +70
Storage Temperature (¢J) -30 ¡ã +80
Weight (g) 2.5
Case material and colour ABS/Blue
*Value applying rated voltage (DC)
¡@
¡@
¡@
¡@
